车用连接器

■技术参数(SPECIFICATIONS)
口适用线规(Applicable wires):AWG24#~16#
口温度范围(Temperature range):-25℃~85℃
口额定电压(Voltage rating):300V.AC/DC
口额定电流(Current rating):10A
口接触电阻(Contact resistance):≤0.01Ω
口绝缘电阻(Insulation resistance):≥1000MΩ
口耐压(Withstand voltage):1500V.AC/1min
口材料(Material):
口孔座(Houshing):尼龙(PA66)UL94V-2(0)
口端子(Terminal):黄铜
